Dimensions

Technical Specifications

Audio

• External Audio Input: 3.5mm TRS input jack on camera; USB audio interface via USB-C; Microphone connected to mobile device; Mevo Go app (wireless audio from mobile device)
• Audio Codec: AAC - 48kHz, 16-bit at 128mbps bitrate
• Built-in Audio: Yes
• Built-in mic: Three MEMS microphone array with Fraunhofer upHear® Spatial microphone processing

General Specifications

• Cable length: 2 meters
• Battery: Up to 6 hours of battery life
• Other info: Additional features and functions accessible via Mevo native applications: Mevo Camera App, Mevo Multicam App, Mevo Wireless Webcam App
• Connectivity: Wi-Fi: 802.11ac @ 2.4GHz / 5GHz, dual antennas, 2x2 MIMO, Access Point Mode: Camera can create its own Wi-Fi network, Join existing Wi-Fi networks for streaming; LTE: Via connected mobile device using Mevo mobile app; Ethernet: Supported via USB-C Ethernet power adapter, Power over Ethernet (PoE) also supported via adapter; USB-C: Connects directly to computer as a webcam (UVC)
• Bluetooth: Bluetooth 4.1 - BT and BLE compatible
• I/O: USB-C, 3.5mm TRS, Micro SD slot
• Memory Card Compatibility: Micro SD (SD, SDHC, SDXC), Memory Not Included
• Button: Rear button used to power on-off, start/stop streaming and/or recording (configurable via app)
• Indicator: Front RGB LED tally light, Four white battery indicator LEDs
• Speaker: Buzzer
• Operating Temperature: 0 - 35 degrees C
• Mounting options: Built-in microphone stand thread (female 5/8-in-27); Mounting Accessory Adapter for mounting to standard tripods (1/4-in-20 UNC and 3/8-in-16 threads)
• Privacy shutter: No
• USB connectivity: USB-A to USB-C

Video

• Camera mega pixel: 2.07 Megapixels
• Digital zoom: Yes
• Focus type: Fixed
• Lens type: Low distortion; 8 elements; f2.8; Focal length 3.6mm
• Max Video Resolution: Recording up to 1080p30 up to 50Mbps; Streaming up to 1080p30 up to 15Mbps
• Supported resolutions: Recording (MP4): 1080p30 at 20Mbps (Max 50Mbps); 720p30 at 10Mbps; Streaming: 1080p30 up to 6Mbps; 720p30 up to 3.5Mbps; 480p30 up to 1.5Mbps; 360p30 up to 1Mbps
• Aspect Ratio: 16:9
• Electronic Image Stabilization: Yes
• Vertical Image Flip: Yes
• HDR: Yes
• Video Output: Direct to Streaming Platform - Integrated API or RTMP(S) via App; USB-C (UVC): Stream as webcam to computers; NDI®-enabled: IP-based video streaming; SRT-enabled: Secure, low-latency IP streaming; MicroSD: Local recording of video
• Exposure Metering: Center, Average, Spot
• White Balance: Auto, Manual via App, Preset via App
• Exposure Compensation: Auto, Manual adjustment from -2.0 to +2.0 EV via App
• Streaming Bandwidth Requirements: Full HD (1080p): Requires a minimum steady upload speed of 6Mbps. Test upload speed at your intended streaming location using Fast.com.
• Video technology: Codec: H.264 and HEVC
